Optical fiber requirements:
- Material: Silica glass
- Fiber count: 1
- Profile types: SMF (G.652),MMF(G.651),DSF(G.653),NZDSF(G.655),BIF(G.657)
- Fiber diameter: Cladding diameter: 125µm; Coating diameter : 250µm, 500µm, 900µm
- Applicable cable: Drop cable (2.0x3.1or 2.6 mmm), Indoor cable (2.0x1.6 mm)
- Cleave length: 5-10mm
Standard performance
- Splice loss (typical): SMF:0.05dB, MMF:0.03dB, DSF:0.08dB, NZDSF:0.08dB (With identical Sumitomo fibres)
- Splice time (typical): Approx.11 sec (1C SMF)
- Heating time: Approx.30 sec (with FPS-61-2.6 sleeve)
- Splice & Heat cycles per battery full charge: 100 (BU-12L)
- Fiber view & magnification: 2 CMOS cameras observation; 72X (Z00M:216X)
- Proof test: 1.96 - 2.09N
Programs
- Splice programs: Max. 200
- Heating programs: Max. 100
Functions
- Splice image capture/ Splice data storage: 64 images /10,000 splices
- Onboard user training video: Provided for basic operation and daily maintenance
- Auto-start: Splice/Heating
- Automatic arc calibration: Automatically optimizes arc power according to environmental conditions (Auto mode)
- Remote interactive maintenance: Provided
Size/Weight
- Size: 110(W) x 140(D) x 176(H) mm
- Weight: 620g (without Battery)/770g(with Battery BU-12S)/860g (with Battery BU-12L)
- Monitor: 3.5" color monitor with touch screen
Terminals:
- USB port: USB 2.0 (mini-B type)
- Storage media: microSD and microSDHC
Power supply:
- AC input: AC100~240V, 50/60Hz
- DC input: DC 10 ~ 15V, 4.5A
- Battery pack: Li-ion 11.1V, 3060mAh (BU-12L)
Electrode life: 3,000 arc discharges
