Number of channels: 4
Communication mode: RS232/LAN
Additional output voltage: 12V/500mA，this voltage strictly prohibit reverse connected
Baud rate: Default 19200bps
Input voltage: 100-240VAC
Input frequency range: 50/60Hz
Output voltage: 24V
Luminance adjustment method: Manual encoder knob adjustment, PC remote adjustment
Luminance adjustment mode: PWM adjust
Luminance adjustment level: 256 level
Memory function: Default setting is data saving automatically when power off. Can be set as not save.
Constant on / off switch: Adjust the state of H mode through the encoder knob, H1 is the constant on mode, H0 is the constant off mode
External trigger voltage: Pulse width trigger High level 5-24V effective
External trigger frequency: It is determined by the mode of external trigger signal. If the duty ratio of external trigger signal is 50%, the maximum external effective trigger frequency is 4KHz
External trigger delay time: 10us
Operating environment: Humidity 20%-85%RH(Frost free state) Temperature 0℃-50℃
Storage environment: Humidity 20%-85%RH(Frost free state) Temperature 0℃-50℃
Total output power: 120W
One way Max. output power: 60W
Dimension: 1
Remark: Communication, external trigger, luminance level display and etc.
