Distance measurement:
Min. measuring range [m]: 0.2
Max. measuring range [m]: 20
Max. typical range: 10 m
Resolution: 1 mm
Typical measuring tolerance: +/-3
Wurfweite Laser-Anreißlinie [m]: 10
Laser:
class: 2
Laserfarbe: rot
output < [mW]: 1
Wavelength [nm]: 670 nm
Display:
LCD (schwarz/weiß) 1,3":
Device control:
Push buttons: ✓
Housing design:
Plastics: ✓
Aluminium: ✓
Power supply:
Internal (battery): 3,7V Li-ion, 300 mAh
Ambient conditions:
Operation - min. temperature [°C]: -10
Operation - max. temperature [°C]: 50
Storage - min. temperature [°C]: -20
Storage - max. temperature [°C]: 60
Dimensions:
Width (packaging excluded) [mm]: 229
Height (packaging excluded) [mm]: 48
Depth (packaging excluded) [mm]: 19
Weight: (packaging excluded) [kg]: 0.217
