Trotec TTR 8200 산업용 제습기 (46.2 kg/h; 8200 m³/h)

General technical data (at 20 ° C / 60% rh, 1013 mbar)

Dehumidification 46.2 kg/h

Dry air

+ Air volume free-blowing 9000 m³/h

+ Air volume nominal 8200 m³/h

+ Compression 400 Pa

Regeneration air

+ Air volume 1660 m³/h

+ Compression 300 Pa

Heating 57 kW

Power input 64.5 kW

Voltage 3/PE/380 - 480 V/50 - 60 Hz

Max. current consumption (@ 3 x 400 V) 93.5 A

Recommended fusing 125 A

Weight 750 kg

Dimensions (L x W x H) 1919 mm x 1110 mm x 1680mm
