Sensor: CMOS sensor (1280 x 960 pixels)
Illumination: 610nm, Green LED
Scan Rate: 30 frames per second
Pitch Angle: ± 60°
Print Contrast: Minimum 20%
Depth of Field: (DOF PCS=80%)
SYMBOLOGY / X-DIM TYPICAL RANGE* Near │ Far
5 mil Code 39 │ 2.4 in / 6.1 cm │ 9.5 in / 24.1 cm
5 mil Code 128 │ 2.8 in / 7.1 cm │ 9.0 in / 22.9 cm
6.67 mil PDF417 │ 2.4 in / 6.1 cm │ 8.0 in / 20.3 cm
10 mil Data Matrix │ 2.9 in / 7.4 cm │ 8.5 in / 21.6 cm
100% UPC │ 1.8 in / 4.6 cm │ 19.5 in / 49.5 cm
15 mil QR │ 1.2 in / 3.0 cm │ 11.5 in / 29.2 cm
20 mil QR Code │ 1.5 in / 3.8 cm │ 11.5 in / 29.2 cm
Bluetooth: Bluetooth Low Energy 4.2
Wireless Coverage: Up to 100M (Open space)
Supported Host Interface: Micro USB
Dimensions: 50x71x21mm
Weight: 95g
Trigger Switch Life: 1 million cycles
Operating Modes: Trigger Mode, Presentation Mode, Auto Mode, Batch Mode
Barcodes: 1D, 2D
Operating Voltage: DC 5V ± 10%
Current Consumption: Operating mode: 160mA, Standby mode: 23mA, Power-off mode: 1uA
ESD Protection: Functions after 8K Contact and 12K Air
Mechanical Shock: 1.5M drop to concrete (scanner only)
Operating Temperature: -10°C to 50°C
Storage Temperature: -20°C to 60°C
Relative Humidity: 95% non-condensing
Standard: IP42
Accessories (optional): Battery, Hand strap, Micro USB cable, 4-slot battery charger (optional)
Certifications: CE, FCC, BSMI, VCCI, TELEC, NCC
