Sensor: Laser engine
Aiming Element: Visible laser diode 650 nm
Pitch Angle: ±40 degrees from normal
Optical Resolution: 4 mil
Depth of Field (DOF PCS=80%)
Symbology | Density | Near | Far
Code 128, 5 mils | 3.05 cm | 19.56 cm
Code 39, 5 mils | 3.05 cm | 31.75 cm
Code 39, 7.5 mils | 2.79 cm | 46.99 cm
Code 128, 10 mils | 3.05 cm | 48.26 cm
UPC, 13 mils | 4.06 cm | 68.58 cm
Code 128, 15 mils | 2.54 cm | 74.93 cm
Code 39, 20 mils | 3.56 cm | 132.08 cm
Code 39, 55 mils | 8.64 cm | 254.00 cm
Code 39, 100 mils | 60.96 cm | 518.16 cm
Supported Host Interface: USB
Dimensions: 36.9mm x 95.9mm x 21.1mm
Weight: 63g
Barcodes: 1D
Operating Voltage: DC 3V to 5V
Current Consumption: Operating Mode: <125mAh, Standby Mode: <39mAh
ESD Protection: Functions after 8K Contact and 12K Air
Mechanical Shock: 1.5m drop to concrete (scanner only)
Operating Temperature: 0°C to 50°C
Storage Temperature: -30°C to 70°C
Protection Class: IP42
Accessories (Optional):
■ Lanyard Beeper
■ Micro USB to USB Converter Cable
■ 1 & 5 Slot Charging Cradle (optional)
Certifications: CE, FCC, BSMI, VCCI
Memory: 64 Kbyte SRAM / 2 MB Flash ROM
Key: 3 keys: Page Up, Page Down, Scan with power, power on/off feature
Wireless Coverage: Up to 30m (Open space)
Interface: Wireless SPP & HID profile
Battery Type: Rechargeable Li-ion Battery
Battery Capacity: 680 mAh
Battery Charging Time: Fully charged in approximately 3 hours
Operating Time: 8 hours at 1 scan/5 seconds
Scan Rate: 104 scans/second
Bluetooth: Bluetooth 2.1+EDR
Display: 1 inch OLED, 128 x 64
Operating System: Proprietary, Connects to host with Windows, Android and iOS
