Display: 1 inch OLED, 128 x 64
Operating System: Proprietary, Connects to host with Windows, Android and iOS
Memory: 64 Kbyte SRAM / 2 MB Flash ROM
Keys: 3 keys: Page Up, Page Down, Scan with power, power on/off feature
Sensor: CMOS sensor with 640 x 480 pixels
Illumination: White LED with CCT 5000K
Scan Rate: 30 frames per second
Pitch Angle: ± 45°
Optical Resolution: Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus
Print Contrast: 35%
Depth of Field: (DOF PCS=80%)
Symbology | Density | Near | Far
100% UPC | 5.5 cm | 28 cm
Code 39, 5 mils | 6.1 cm | 13 cm
Code 39, 20 mils | 6 cm | 38 cm
PDF417, 6.7 mils | 6 cm | 12.5 cm
Data Matrix, 10 mil | 6 cm | 13 cm
QR, 20 mil | 5 cm | 23 cm
Bluetooth: Bluetooth 2.1+EDR, Class 2
Wireless Coverage: Up to 30 feet (Open space)
Interface: Wireless SPP & HID profile
Supported Host Interface: Micro USB
Dimensions: H21.1W36.9L95.9mm
Weight: 63g
Trigger Switch Life: 10 million cycles
Operating Modes: Trigger Mode, Presentation Mode, Auto Mode, Batch Mode, Wedge Mode
Barcodes: 1D, 2D
Operating Voltage: DC 3V to 5V
Current Consumption: Operating: 400mA, Standby: 160mA
Battery Type: Rechargeable Li-ion Battery
Battery Capacity: 680mAh
Battery Charging Time: Fully charged within 4 hours
Operating Time: 5 hours at 1 scan/5 seconds
ESD Protection: Functions after 8K Contact and 12K Air
Mechanical Shock: 1.5m drop to concrete (scanner only)
Operating Temperature: 0°C to 50°C
Storage Temperature: -30°C to 70°C
Relative Humidity: 95% non-condensing
Standard: IP42
Accessories (optional):
■ Lanyard Beeper
■ Micro USB to USB Converter Cable
■ 1 & 5 Slot Charging Cradle (optional)
Certifications: CE, FCC, BSMI, VCCI
