Lens parameter
Resolution: 260*200
Frame rate: 25Hz
NETD: 70mK 25℃
Field of view: 34.4 horizontal,25.8 vertical
Lens: 4mm adjustable focus lens
Temperature range: -10~120℃
Precision: 士5℃ or ±5%
Interface
Powered by: DC5V(USB Type-C)
Switch:
Power on in 1 second
power off in 3 seconds
Connection method: USB
Physical value
Size: Standard configuration: 220*172*241mm
Optional: split double, bottom plate: 346*220mm, extended support rod 341mm
Weight:
Standard configuration: 1.1kg
Optional accessories: 0.5kg
Surroundings
Operating temperature: -10℃~55℃
Working humidity: <95%
Software and hardware
System: Win10/Win7
Computer: i3 or higher processor 4G RAM
Renew: Connect to the Internet formanual or automatic updates
