Max.Drilling capacity: 31.75mm
Max.Tapping capacity: M24(cast iron)/M20(steel)
Diameter of column: Φ100
Spindle travel: 150mm
Distance spindle axis to column: 265mm
Max.Distance spindle nose to table: 390mm
Max.Distance spindle nose to base: 745mm
Spindle Taper: MT3
No. of Speeds: 5speeds
Spindle speeds range: 280~1875r/min
Dimension of workable surface: 380x400mm
Dimension of base: 645x470mm
Overall height: 1370mm
Motor: 1.5KW(4P)
Approx.net weight: 230kg
Packing size: 1039x644x1512mm
