Honing hole diameter: 40-170mm
Maximum depth of honing hole: 320mm
Rotation of main shaft: 120,160,225,290r/min
Stroke of main shaft: 35,44,60s/min
Horizontal motion distance of main shaft: 900mm
Lifting height of machine table: 150mm
Power of main motor: 1.5kw
Voltage: 3～380V
Frequency: 50Hz
Power of cooling pump: 125w
Voltage: 3～380V
Overall dimensions (L×W×H): 1640×1670×1920mm
Weight of machine proper: 820kgs
Honing heads:
1) MFQ40: Φ40~Φ62
3) MFQ60: Φ60~Φ82
3) MFQ80: Φ80~Φ120
4) MFQ120: Φ120~Φ170
