Max.cutting length(interpolated inner hole 360 mm: 400mm
Max.weight of the work piece: 500kg
Max.cutting force: 750N
The number of reciprocation per minute of the ram: 20.32.50.80
Ram vertical adjustment distance: 315mm
Ram tilt angle: 0-8°
Max.size of the plug (width×height): 25×40mm
Table diameter: 630mm
Distance between the support surface of the cutter head and the front wall of the bed: 600mm
Work surface of the lower end of the carriage: 690mm
Worktable Max.longitudinal movement distance: 620mm
Worktable Max.lateral movement distance: 560mm
Worktable vertical and horizontal maneuvering feed range: 0.08-1.21mm
Worktable rotary maneuvering feed range: 0.052-0.783deg
Main motor power: 4kw
Main motor speed: 960rpm
Machine size (L×W×H): 2290 ×1525×2485mm
Weight: 3700kg
