Wrindu RDLI-3655 Lithium Battery Equalization Tester (Test Port: 3*12)

Test Port: 3*12

Charge & Discharge Power: Max 900W

Voltage Range & Accuracy: 1.8-4.2V @±0.1%FS±2mV

Current Range & Accuracy: 0.1-5A @±1%FS±0.05A

Temp Range & Accuracy: -25～85℃@±2℃

Baery Port: 17pin/26pin

Display: 7 inch touch screen

PC Data Communicaon: TCP/IP, USB

Wireless Communicaon: WIFI, BT (WIFI antenna external)

Charge Mode: Constant current charging + constant voltage charging

Discharge Mode: Constant current discharge

Dimension: 480*255*430mm/18kg
