Supports all common ISP protocol (i.e. I2C, SPI, UART, BDM, MW, JTAG, CAN, RS232)
PC interface: USB2.0 (high speed), LAN (100M)
Off-line memory media: SD card
Keypad: 6-key keyboard
Display: LCD display with 40 digits x 4 lines
Power Supply: DC 12V/1.5A; Power adapter
Main Unit:
+ Dimension: 184x160x78mm
+ Weight: 0.8kg
Operating Temperature: 0~50°C
Humidity: 20~80%
Item included:
+ 4 ISP Cables
+ Software CD
+ AC Adapter
+ USB Cable
+ SD Card for stand-alone operation
Optional Accessories:
+ Command Line Utility
+ DLL License
+ ISP Cables
