Water purifying method: Ion-exchange→Distillation
Water feeding: One-touch coupler water connection, with water stop valve
Water discharging: Left/right selection for connecting hose
Collection of distilled water: Deionized water/Distilled water
Distilled water production: Approx. 1.5L/h
Distilled water delivery rate: Approx. 1L/min
Deionized water delivery rate: Approx. 1L/min
Range of production: Continuous production
Condenser: Hard glass
Heater: Ceramic heater 1.2kW
Pre-treatment cartridge: 0.1μm diameter hollow fiber + Activated carbon
Ion-exchange resin cartridge: CPC-S 4L×1pc. (Activated carbon high-purity cartridge)
Distilled/deionized water filter: Option
Leakage indication: Forced shutdown of solenoid valve by water leakage sensor
Distilled water tank capacity: 20L polyethylene tank
Multi-purpose distilled water sampling port: Right side of main unit, 1pc.
Water level sensor: 2 steps reed switch
Raw water pressure range: 0.5 to 5×100kPa (0.5 to 5kgf/cm2)
Accessories: Feed /drain water hose 2m, Connecting hose assembly, Pre-treatment cartridge, Ion-exchange resin cartridge, Hose clamp
External dimensions（W×D×H mm）: 600×575×780mm
Power Source: AC115V/AC220V Single-phase with step-down transformer
Weight: 48kg
