YATO YT-730944 Digital Multimeter (750VAC, 1000VDC, 10AAC/DC, True RMS)

AC voltage measurement: 0–750 V AC

DC voltage measurement: 0–1000 V DC

AC current measurement: 0–10 A

DC current measurement: 0–10 A

Resistance measurement: 0–250 MΩ

Capacitance measurement: 0–99.99 mF

Frequency measurement: 0–999.9 kHz

Continuity test: yes

Diode test: yes

Minimum value measurement (MIN): yes

Maximum value measurement (MAX): yes

Relative value measurement: yes

Average value measurement: yes

Number of functions: 3

Functions: multimeter, dual-channel oscilloscope, basic waveform generator

TRUE RMS: yes

Data Hold: yes

Bandwidth: 50 MHz

Number of channels: 2

Dimensions: 177 × 89 × 40 mm

Material: ABS

Display type: IPS LCD

LED backlight: yes

Display count: 25,000

Auto-ranging: yes

Automatic calibration: yes (oscilloscope)

Memory depth: 128 Kpts

Sampling rate: 3 readings/s (multimeter), 280 MSa/s (oscilloscope)

Audible signal: yes

Auto power-off: 15, 30, 60, or 120 min

Oscilloscope probe settings: ×1, ×10

Flashlight function: no

Low battery indicator: yes

Power supply: rechargeable battery

Battery type: Li-Ion

Battery voltage: 3.7 V DC

Battery capacity: 3400 mAh

Battery energy: 12.58 Wh

Operating temperature: 0 ~ 40°C

Operating relative humidity (Rh): <75%

Storage temperature: -10 ~ +50°C

Weight: 0.38 kg

Application: electrical measurements, diagnostics, and waveform analysis.
