Capacity (Optional): 250N, 500N,1kN, 2.5kN, 5kN, 10kN, 20kN, 30kN, 50kN
Unit (switchable): N,kN,kgf,Lbf,MPa,Lbf/In²,kgf/mm²
Load Resolution: 1/25,000
Accuracy Grade of Machine: 1 Level
Load Magnifying Rate: Section-less
Max Stroke (Exclude the Grips): 1000mm, others (Customized)
Effective Width: 400 mm(Below 30kN), 500 mm(50kN Type)
Test speed: 10 ~ 100mm/min, others(Customized)
Speed accuracy: ± 1%
Displacement Resolution: 0.00125mm
Software: Standard control software
Motor: AC motor
Transmission Rod: High accuracy of ball screw
Main Unit Dimension (WxDxH): 1080x540x1775 mm (Below 30kN)
1280x620x2005 mm (50kN type)
Power: AC220/50HZ 10A or specified by user
