Compact USB Bridge/Strain Gage Data Logger with Large Storage OMEGA OM-CP-BRIDGE101A-150MV (Strain, ± 160 mV)

Width: 16 mm

Height: 64 mm

Length: 36 mm

Memory: 1,000,000 Readings

Weight: 24 g

Software: Windows XP SP3 / Vista / 7 and 8 (32 and 64 - bit)

Approvals: CE

Baud Rate: 115200

Materials: ABS

Input Note: ±150 mV

Resolution: Strain: 5 µV

Stop Modes: Manual Through Software

Memory Note: 1,000,000 readings; software configurable memory wrap 333,000 readings in multiple start/stop mode

Start Modes: Delayed Start, Immediate Start

Battery life: 10 mo

Memory Modes: Yes

Accuracy Note: Calibration Accuracy : Strain: ±0.01% FSR; ±16 microvolts; Time Accuracy : ±1 minute/month at 20ºC (68ºF), stand alone data logging

Pressure Type: N/A

Pressure, Max: 0 psi

Sampling Rate: 4 Hz (4 updates/second)

Time Accuracy: ±1 minute/month

Data Interface: USB

Humidity Range: 0 to 90% RH non-condensing

LED Indicators: Green LED Blinks: 10 second rate to indicate logging; 15 second rate to indicate delay start mode;Red LED Blinks: 10 second rate to indicate low battery and/or full memory; 1 second rate to indicate an alarm condition

Data protection: Access by password

Millivolt Range: ± 160 mV

Measurement Type: Strain

Supply Power Type: Battery

Sampling Rate Note: 4 Hz to 1 every 24 hours

Real Time Recording: The device may be used with PC to monitor and record data in real-time

Calibration Accuracy: Strain : ±0.01%

Input Control Signal: 0 to 2.5 V

Battery Size and Type: 3.6V Li-ion

Number of Measurements: 1

Process Connection Size: N/A

Process Connection Type: N/A

Multi Start/Stop Mode Note: To Start the Device: Press and hold the pushbutton for five seconds, the green LED will flash during this time. The device has started logging, To Stop the Device: Press and hold the pushbutton for five seconds, the red LED will flash during this time. The device has stopped logging, Real Time Recording: The device may be used with PC to monitor and record data in real-time

Operating Temperature, Max: 80 °C

Operating Temperature, Min: -40 °C
