Alluris FMI-M10B1 Mechanical Force Gauge Spring Balance (10N)

Capacity F(nom) (N ): 10N

Resolution( N): 0.1

Tolerance (% F(nom) ): 3

Temperature coefficient( % / K ): 0.05

Reproducibility (% F ): 0.6

Repeatability (% F): 0.6

Hysteresis (% F ): 1.5

Measuring principle : Tension spring with direct scaling

Nominal deflection mm: 100

Application of force : Bracket and tow hook

Accessories:

Drag ring:  included

Handle: -

Accessories:

Push rod (optional) : FMT-918

Calibration Certificate:

ISO 9001 certified : -

ISO 17025 accredited:  CAL-210B5Z
