Measuring Range:
contact measurement : 6...25,000 RPM
non-contact : 6...99,999 RPM
measuring distance: ca. 50...800 mm
Measuring Principle: photo optical detection of a reflected laser beam
Operation Mode:
revolution : RPM contact | non-contac
speed: m/min | yd/min | ft/min | in/min -
distance / length: m | yd | ft -
totalise / count: number of revolution -
Accuracy:
revolution : 0.006% (+/-1RPM)
speed / distance : 0.4% (+/- 1Digit) -
Resolution:
revolution : 1 pulse / revolution
distance: 0.02362m/pulse
Display:
type: LCD. 5-digit. 12mm high
update time : 1000 msec
Memory:
min / max / last : Yes
additional values: 10 recordable values
Batteries number / type: 3 x 1.5V AA-Typ
live time: ca. 35 h
low battery indication : yes
Temperature Range operation : 0...45° C
Weight : 200 g
Dimensions LxWxH : 149 x 64 x 31 mm
Housing material : Polyamid. reinforced
