Frequency range: 30 MHz to 1 GHz
Typical gain: 5 dB
Impedance (nominal): 50 Ω
Maximum continuous power: 300 W
Connector: N type female
VSWR: Average 2:1
Size antenna (L x H x W in mm): approx. 1310 X 1390 X 630 (see drawing)
Weight: approx. 3.5 kg
Recommended tripod: BTP 6020A
