CEM BT-3700 电池分析仪 (3mΩ-3000mΩ)

Function: Max. Range / Max. Resolution / Basic Accuracy

Battery resistance: 3mΩ / 0.001mΩ / 1 % + 8

                               30mΩ / 0.01mΩ / 0.8 % + 6

                               300mΩ / 0.1mΩ / 0.8 % + 6

                               3000mΩ / 1mΩ / 0.8 % + 6

DCV: 6V / 0.001V / 0.09 % + 5

          60V / 0.01V / 0.09 % + 5

          600V / 0.1V / 0.09 % + 5

          1000V / 1V / 0.09 % + 5

ACV (45 Hz to 500 Hz with 800 Hz filter): 600V / 0.1V / 2 % + 10

Frequency (displayed with ACV and ACA ): 500Hz / 0.1Hz / 0.5 % + 8

AC voltage ripple (20 KHz Max): 600mV / 0.1mV / 3 % + 20

                                                     6000mV / 1V / 3 % + 10

Temperature: 0°C - 60°C / 1°C / 2°C

Meter mode: 999 records for each measurement position with timestamp

Sequence mode: 8p to 100 profiles and 100 profiles templates (Each profile stores up to 450 batteries) with timestamp

Accessories: Test leads, 6x1.5V“AAA” batteries, Type K temperature probe and Software, gift box with carrying case.
