Spectroscopic method: Grating
Image resolution: 1920 * 1920
Dynamic range: 12 bits
Imaging speed: 5s
Spectral channel number: 1200
Spectral range: 400–1000nm
Optical harmonic resolution: 2.5nm
Slit width: 25um
Transmission efficiency: ≥60%
Stray light level: ≤0.5%
Pixel size: 5.86um * 5.86um
Detector type: CMOS
Standard lens focal length: 25mm
Minimum working distance: 100mm
Field angle: 25°
Minimum exposure time: 21us
Maximum exposure time: 10s
Signal-to-noise ratio: 600/1
Data interface: USB3.0
Camera lens interface: C
Attachment: USB3.0
Auxiliary imaging function: The auxiliary view camera monitors the shooting area
