H.F Power: 8KW
Power input: 15KVA
Voltage: AC 380V 3P (Can be customized)
Frequency: 27.12MHz
Driven Mode: Pneumatic
MAX Pressure: 800KGS
Stroke: 200MM
Upper Electrode Size: Curved Electrode, 36mm Width
Lower Electrode Size: Diameter 450mm Disk(Can be Customized)
Oscillation tube: Japan TOSHIBA 7T69RB
Weld time: 1-10 S (Adjustable)
Gross weight: 800 KGS
Dimension: L*W*H: 1295*700*2118 MM
