Specifications
Voltage Range: ±1050 V
Accuracy: ±5 V for values below 100 V
±5 % for values 100 V and above
Resolution: 1 V
Input Resistance: 10^14 ohms
Power Supply: 6 AA alkaline batteries
Battery Auto-Shut Off Timer: 10 minutes
Display: Graphic LCD 128 x 64 pixel, 68 mm x 51 mm
Memory Capacity: 10 graphs
Sample Rate: 200 Hz
Max Total Graphs Duration: 2 minutes and 30 seconds
PC Interface: USB
Operating Temperature: 41 ºF to 85 ºF (5 ºC to 30 ºC)
Environmental Requirements: Indoor use only at altitudes less than 6500 ft. (2 km)
Maximum relative humidity of 80 % up to 85 °F (30 °C)
Dimensions (meter): 9.6" x 5.1" x 2.4"
(243 mm x 130 mm x 60 mm)
Dimensions (probe): Ø 1.4" x 5.1"
(Ø35 mm x 130 mm)
Weight (meter with batteries): 1.4 lbs (650 g)
Weight (probe): 0.6 lbs (0.27 kg)
