Internal Dimension: W2000 X D3000 X H2000 mm
External Dimension: W2400 X D5000 X H3000 mm
Max Load: 1000KG for battery pack
Temp. Range: 0℃～+85℃
Temp. Fluctuation: ±0.5℃
Temp. Deviation: 2℃
Spray Capacity: 1~2mL/80cm2/hr (Collect at least 16 hours, take the average )
Spray Pressure: 1.00±0.01kgf/cm²
Resolution: Temp: 0.01℃, Humidity:0.01%R.H.
Humidity Range: 30%–98%R.H.
Humidity Fluctuation: ±3%R.H.
Potion PH: Neutral 6.0～7.0 Acidity 3.0～3.1
Spray Solution PH: Neutral 6.5～7.2 Acidity 3.1～3.3
Test Time Range: 1S ～ 9999H (Settable)
Control Mode: Touch screen programmable control PLC, networking; mobile phone APP alarm; with USB interface, with RJ485 interface can be connected to computer control, exclusive network control software. Remote monitoring and data acquisition.
Internal material: Acid and alkali resistant SUS316 material
External material: Cold and heat resistant steel plate with spray coating
Cooling Mode: Air cooling / water cooling
Total Weight: Approx 7 Tons
Power Supply: AC 380V, 55KW
Other Auxiliary Functions: *Main-subsidiary type trolley for the specimen in and out of the test chamber.*Explosion-proof, Pressure relief, Smoke Exhaust, Fire extinguishing, Video monitoring.
