Evikon E2608-VOC Solvent Vapors Detector (0~1000 ppm)

Calibration: acetone, ethanol, toluene, xylene etc

Default calibration: toluene

Sensor type: metal-oxide semiconductor

Sampling method: Diffusion

Detection range: 0...100% LEL (flammable range)

                           0...1000 ppm (toxic range)

Resolution: 0.1% LEL for LEL range

                    1 ppm for ppm range

Sensor lifetime: > 5 years

Power supply: 12...36 VDC (default), 24 VAC or 230 VAC as options

Digital interface: RS485, Modbus RTU protocol

Analog outputs: 2 × 4-20 mA / 0-10 V, user settable

Output relays: 2 × SPST relays (closing contact), 250 VAC / 30 VDC, 5A max

Default alarm setpoints: 20% LEL / 50% LEL

                                       100 ppm / 300 ppm

Enclosure: grey ABS plastic, wall mount, IP65

Dimensions: H85 × W82 × D55 mm

Operating conditions: -30...+70 °C, < 95%RH
