Controller: Touch screen+PLC programmable control
Load cell: Celtron,5KN
Platen:
Weight: 79.5 ± 1kg
Diameter: 356±10mm
Thickness: 91±5mm
Convex spherical curvature radius: 300 mm
Edge radius: 25±2.5mm
Power supply: 1∮, AC 220V 50/60Hz
Dimension (WxDxH): W750×D1900×H1800mm
Weight: ≈450Kg
Standards: ASTM F1566 section 8
