Measurement range: depends on detector
Calibration: Factory calibration of amplifier, traceable to national standards
Sensor: BNC connector (-1)
min. signal current: 0.1 pA
Max. signal current: 20 µA
Microprocessor: 16Bit, 25ns instruction cycle time
Power Supply: 5VDC, 450mA per USB
Interface: USB 2.0 (Type B USB)
Option WiFi: WiFi 2.4 GHz (external antenna, range > 100m) on request
Temperature range
Operation: +10°C bis +30°C
Storage: -10°C bis +50°C
Transport case: 333mm x 280mm x 70mm, 650g
Dimensions: 159mm x 85mm x 45mm (Length x Width x Height)
Weight: 430 g
