GW INSTEK LCR-1100 手持式LCR测量仪

Test Frequency: 50/100/120Hz/1k/2k/10k/50k/100kHz

Display: Primary / Secondary: 50.000 counts

Output Impedance: 100Ω

Basic Accuracy: 0.2%

Test Speed: Slow: 2,5 times/s, Fast: 10 times/s

Test Signal Level: 0.3V/0.7V/1.0 Vrms selectable

Tesst Parameters: CD, CQ, CR, LD, LQ, LR, L-Rdc, RQ, RX, R-Rdc, Rdc, ZD, ZQ, Z-θr, Z-θd

Equivalent Circuit: Series / Parallel selectable
