Display model: Small LCD Digital Display
Hardness values: Input D1,D2
Exchange scales: HRA, HRB, HRC, HRD, HRF, HV, HK, HBW, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T
Test force: 10gf (0.098N), 25gf (0.245N), 50gf (0.49N), 100gf (0.98N), 200gf (1.96N), 300gf (2.94N), 500gf(4.9N), 1kgf (9.8N)
Turret type: Automatic
Loading and unloading mode: Automatic
Dwell Time: Adjustable 0 to 60 seconds
Micrometer eyepiece multiple: 10X (optional 15X)
Me measurement resolution: 0.25µm (drum reading)
Objective magnification: 10X 40X
Total magnification: 100X (objective) 400X (measurement)
Measurement range: 150µm
Light source: Halogen lamp (brightness adjustable)
Hardness conversion: Brinell, rockwell, surface rockwell
Max. height of specimen: 80mm
Depth at center line: 95mm
XY test table size: 100X100mm Max. movement: 25*25mm
Min. measuring unit: 0.01μm
