Max. Load: 100kN
Range of test force: 4-100kN
Test space adjusting mode: Block adjustment test space
Control mode: Manual control loading process
Value repeatability error: ≤±1%
Loading speed: 0.3KN/S~10KN/S
Loading speed error: ±5%
Piston stroke: 60mm
Max compression space between two plates: 180
Working table size: 150mm×200mm
Dimension: 1200x550x1400mm
Main configuration:
Main unit and oil source control cabinet: 1 set
High precision compression sensor: 1 pc
English version operate instrument: 1 suit
Micro printers: 1 set
Specialized compression attachment: 1 suit
Bending fixture: 1 suit(Optional)
Accompany tools: 1 suit
Accompany documents: 1suit
PC stand-alone software: 1 set
Connection line between PC and machine: 1 pcs
