Jaw Size (mm): 65×32
Range of Resistance (Ω): 0.01-1200
Storage Function: 99 Units
Instrument safety: IEC/EN61010-1, IEC/EN6010-2-032
Insulation: double insulation
Pollution degree: class II
Overvoltage category: CAT III 150V to ground, Max 20A
Degrees of protection:
IP30, Group III equipment as per EN 60529 Ed 92
IK04, as per EN 50102 Ed 95
Dimensions(L×W×H):
Long elliptic jaw: 285mm×90mm×66mm; (11×4×3 inches)
Round jaw: 260mm×90mm×66mm;(10×4×3 inches)
Span of Jaw: Long elliptic jaw 35mm; round jaw 32mm
Weight (including batteries): Long elliptic jaw-1160g, Round jaw-1120g
Battery type: 4 ×1.5V alkaline LR6 AA battery
Internal consumption: <50mA
Auto Power off: after 5 minutes of idleness
Display: 4 LCD, sign, decimal point and backlight
Memory size: 99 Units of Reading
Environment (Temperature & Relative Humidity):
Working: -10°C~55°C, 10%RH-90%RH
Storage: -20°C ~60°C, below 70%RH
Range shift: Full range automatic shifting
External magnetic field: <40A/m
External electric field: <1V/m
Data upload interface: RS232 (Optional)
