Rated input voltage (V): three-phase AC380V±15%; 50 Hz
Rated input current: 12A
Rated voltage: 8.4 KVA
Rated output in MIG mode (A/V): 50/16.5 – 270/27.5
Load cycle: 60%
No-load voltage: 52 V
Stick welding current adjustment range: 20-220A
Efficiency: 85%
Power factor: 0.93
Protection class: IP21S
Insulation class: F
Wire supply type: Separate wire supply
Welding current diameter: 0.8-1.2 mm
Weight of MIG welding wire coil: 15 kg
Wire feed speed: 1.5-18m/min
Cooling type: air cooled
Accessories
Wire feeder with 5m welding cable
24KD welding gun 3m long
Cooling clamp with 3m welding cable
CO2 meter
