With 30/60/90 degree engraved projection screen and clamping reed: Φ1000mm
Transmission projection system with adjustable halogen lamp and cooling fan: Yes
Reflection projection system with 800W 220V adjustable halogen light source and cooling fan: Optional
Overheating automatic protection: Yes
Standby function: Yes
Standard workbench: Yes
Optical accuracy: 0.05% profile, 0.1% surface
Working desk size: 800X200mm
Electric horizontal movement range: 400mm
Electric vertical movement range: 250mm
Manual focus range (automatically selectable): ±25mm
Rotation angle: +15°
Load-bearing: 200kg
Optional lens: 10X/20X/50X/100X
Optional lens: 5X/25X
