Applicable instrument: E4982A, E4990A + 42942A*, E4991B, E5061B-3L3/3L4/3L5 with Opt. 005 + 16201A
* Option E4990A-120 is required
Frequency:
DC to 500 MHz (with open and short compensation)
DC to 2 GHz (with open and short and load compensation)
Maximum voltage: ±42 V peak max. (AC +DC)
Operating temperature: –55 to +200°C
Dimensions (approx.): 150 (W) x 40 (H) x 80 (D) [mm]
Weight (approx.): 350 g
