KoCoS ACTAS CF80 Stationary Switchgear Test System

Closing coils: 1

Opening coils: 1

Relay control outputs: –

Analog control outputs (0…10 VDC): 2

Coil current: 2 × (I/O)

Coil / station voltage: 1

Motor current via shunt: 1

Motor voltage: 1

Sensor (digital / incremental): 1 per drive

Sensor (+/−10 V): –

Sensor (0…20 mA): –

Main and PIR contacts: 3 × 2

Auxiliary switch contacts: –

Reference voltage for external sensors: –

Datasheet
