Bandwidth: 500MHz
Rise Time: ≤0.7ns
Analog channels: 4
Real-time sampling rate: 3GSa/s
Memory Depth: 360Mpts
Max. waveform capture rate: 230,000wfms/s
Configuration: Basic Software
Baseline Noise < 85μVrms
Vertical Resolution: 12bit
Input Impedance: 50Ω / 1MΩ
Bus decoding: RS-232/422/485/UART、CAN、CAN FD、LIN、SPI、I²C、ARINC429、1553B
Interface: USB 3.0/2.0 Host, USB Type-C, LAN、SFP+、HDMI、Trigger in/out、10MHz in/out
Trigger: Edge, Pulse width, Logic, Nth-edge, Runt, Slope, Timeout, Video, Serial bus
Dimension: 224.5*30*264.3mm(Width x Height x Depth)
