Test force: 1.0Kgf(9.8N); 3.0Kgf(29.4N); 5.0Kgf(49.0N); 10Kgf(98.0N; 20Kgf(196N); 30Kgf(294N)
Hardness test range: 5HV~3000HV
Objective lens: 10×，20×
Total magnification: 100×，200×
Measuring range: 400μm
Indexing value: 0.1μm
Test force application method: Automatic loading and unloading test force
Turret method: Manual turret
Test force holding time: 0～60s (one unit per second, any input)
Maximum height of specimen: 200mm
The distance from the center of the indenter to the outer wall: 130mm
Voltage: AC220V/50Hz
Dimensions: 620*330*640mm
Weight: About 70Kg
