Measurement Item: Rotation, X,Z axis
Automatic measuring distance Manual measuring range (mm): X:150, [Y:±5〕, Z:160
Display scope: 0.01mT~3.000T
Measuring range: 30mT, 50mT, 100mT, 300mT, 500mT, 1T, 3T, 5T
Resolution: 18.000P/R
Accuracy: DC magnetic field ±2% (full scale of measuring range)
Functions: UHS・1DS+3D display, zero-crossing phase angle calculation, pseudo-waveform comparison, 3D to 2D conversion
Probe options: Transverse type: 50102U, 50103U, 50105U Axial type: 50112U, 50113U
personal computer used: Windows 10 with USB port
Power input: AC100±10(V)5(A)
External dimensions (mm): W450×D430×H830
Weight(kg): approx. 15
