Features
Detection of oxygen percentage by a paramagnetic transducer (O₂ accuracy <0.1%)
Direct reading from colour display (Oxygen, Flow, Air)
Automatic flow control through mass flow
Automatic control of oxygen / nitrogen mixing
Device management by microprocessor
Mixture management with addition of air for cheaper measures with high oxygen concentration
Automatic calibration (0 and 100%)
Flow distributor inside the column
USB output for PC connection
Supply Included
Support for self supporting specimens
Support for non-self supporting specimens
Support for thin specimens
Column Pyrex glass with cap
Burner for the ignition of the sample with manual regulator and gas hose
Clamp for specimen positioning
General
Column: type A Ø100 × 450 h (mm)
Dimensions: 630 × 300 × 570 h (mm)
Net weight: 18 kg
Gross weight: 21 kg
Standard
ASTM D 2863
ISO 4589-2
Power Supplies
Power supply: 230 V 50 Hz single phase
Oxygen
Nitrogen
Propane
Dry industrial air 2 bar
