AC
Output voltage: 0～5kV
Test current: 0～2/20/200mA
DC
Output voltage: 0～5kV
Test current: 0～2/20mA
Test accuracy: ±(5%+3 characters)
Test time: 0.0s～999s 0.0=continuous test
Transformer capacity: 1000VA
PLC interface: Optional
Power supply requirements: AC: 220V±10% 50Hz/60Hz±3Hz
Working environment: Temperature: (0-40)℃ Humidity ≤75%RH
Dimensions (DxWxH): 407*378*193mm
Weight: 24.8kg
Accessories: High voltage test line, high voltage rod, grounding line, power line
Optional: RK8N+, PLC interface, RK-16G, RK101 withstand voltage inspection box
