Max. Working Voltage
DC: 0 ~ 10 KV DC
AC: pulse ≤ 20 KV peak to peak
AC: sine wave ≤ 7 KVrms
Signal/Noise
DC ≥ 60 dB (1 KHz), ≥ 50 dB (1 MHz)
Bandwidth DC ~40 MHz (-3 dB)
Division Ratio 1:1000
Rise Time ≤ 8.8 ns
Input Impedance 100 MΩ ± 5%
Input Capacitance 3.0 pF ± 0.5 pF
Compensation Range 5 pF ~ 50 pF
Cable Length 2.0 meter (± 0.2 M)
Temperature Coefficient ≤ 200 PPM /℃
Accuracy
DC ± 3% (DC to 10 KV)
AC ± 3% (1 KHz/1 KV ), -3dB 40 MHz
Safety App. CE
Operating Temperature 0 ~ 50℃
Storage Temperature -20 ~ +70℃
Weight / Dimension 250 g / Φ75 x 340 mm L
