Time control Precision: 0< ± 0.01% (quartz crystal controller)
Rated output power: 5KW(500V, 10A)
Maximum output voltage: ±1000V
Maximum output current: ±10A
Minimum output current: =< 150mA
Power pulse width: 1–32s bipolar; duty ratio of 1:1
Additional function: Input voltage, output current measurement
Voltage indication accuracy: ±0.2%±1word
Current indication accuracy: ±0.2%±1word
Current memory interval: memory as period interval
Power supply periods: 4”,8” ,16” ,32” and 64” (input 0-996 by hand) MIPI external control
High-capacity data memory: 9000 groups current data (Include the year, month, day, hour, minute and second of the measurement time).
It has ac dump protecting function, can store the data for 25 years.
Internal power consumption: 16V, 130mA,
+ Power supply: 16V, 4.4A
+ Rechargeable lithium battery
Dimension: 430×260×180mm
Weight: 10.5kg
Insulation resistance: >100MΩ
