Depth: 485 mm
Width: 437 mm
Height: 265 mm
Components: Diodes, Diodes ZENER, resistors, capacitors...
Continuity: 1 mΩ to 2kΩ
Insulation: 50 kΩ to 5GΩ
Functionnal: up to 2120 VDC / 1500 VAC
Test points: 2 048 points (extendable)
Dielectric strength: adjustable 500 μA to 10 mA
Max switching cards: 16
