Measurement Range: 0 – 100ppm
Sampling Method: Diffusion
Accuracy: ±3% of Full Scale
Display: 4-digit LCD (55W x 30H mm)
Alarm Output Signal: Relay Contact (30 VDC max, 5A)
Alarm Level: Depends on the measured gas and range
Connection Cables:
4-20mA & Power: CVVSB 1.5sq or AWG 20/2, max 500m
RS-485 Data Transmission: UL 2919 RS-485, 1 pair, max 1200m
Type: Fixed Wall-mounted
Operating Conditions:
Temperature: -20 to 50°C
Humidity: 5 to 95% RH (non-condensing)
Power Supply: 9 ~ 34 VDC, 600mA
Material: Aluminum, Stainless Steel (SS304)
Dimensions (mm): 150W x 165H x 110D
Weight: 1.9 kg
