Wavelength (±20nm): 1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm
Display: 7 inch TFT touch screen (800x480)
Emitter Type: DFB-LD
Spectrum Width: ≤ 5nm
Output Power: ≥ -3dBm
Stability: ≤±0.05dB/5min ≤±0.15dB/8hour
Connector Type: FC/UPC (Interchangeable SC, ST)
Fiber Type: Multi / Single mode Fiber
Power Supply: Rechargeable Li-on battery/AC Adapter
Battery Life: 10 hours continuous operation
Operating Temperature: 0℃ ~ 50℃
Storage Temperature: -20℃ ~ 70℃
Relative Humidity: 0 to 95% (non-condensing)
Weight: 2.1 KG
Dimentions(LxWxH): 290x175x75mm
* Specifications subject to change without notice:
Ordering Information:
Standard Package Includes::
Instrument, FC/PC connector, Li-on rechargeable battery, AC adapter, Soft carrying case, Warranty card, Certificate of calibration, Quick reference guide.
