PON Power Meter:
Calibrated Wavelength: 1310
Measurement Range (dBm): -40 ~ +10(1)
Spectral Passband (nm): 1310±50
Calibrated Wavelength: 1490
Measurement Range (dBm): -40 ~ +12
Spectral Passband (nm): 1490±15
Calibrated Wavelength: 1550
Measurement Range (dBm): -40 ~ +20
Spectral Passband (nm): 1550±10
Power Uncertainty (dB): ≤ 0.5dB
Accuracy (dB): 0.01dB
Insertion Loss (dB): ≤ 1.5dB
Data Storage: >2000 records
OPM Function (only with PPM-51):
Detector Type: InGaAs
Accuracy: ±0.25dB @ 25ºC& -10dBm (±0.5dB@850nm)
Resolution (dB): 0.01
MOD Identification: 270, 1K, 2K Hz
Auto Wavelength Identification : Yes (With SLS-50)
Display: TFT
Connector: FC/PC (Interchangeable SC, ST)
Data Storage: >2000 records
Data Interface: USB
Power Supply: Rechargeable lithium battery (1050mAh) / AC adapter
Battery Life: ≥6 hours
Operating Temperature: -10℃ to 50℃
Storage Temperature: -20℃ to 70℃
Relative Humidity: 0 to 95% (non-condensing)
Weight: 345g
* Specifications subject to change without notice.
Ordering Information
Standard package includes:
Instrument, Lithium battery, Rubber boot, Data transfer cable (USB), PC Software CD, AC adapter, Toolkit for soft bag, Warranty card, CE certificate, Certificate of calibration, User manual.
