Width: 5.85 mm
Height: 4.8 mm
Length: 5.85 mm
LED Size: 5.85 mm x 4.8 mm
Lens Color: Colorless
Lens Shape: Dome
Power Rating: 100 mW
Configuration: Common Cathode
Viewing Angle: 10 deg
Mounting Style: Through Hole
Lens Dimensions: 5 mm
Lens Transparency: Water Clear
Illumination Color: RGB
Luminous Intensity: 700 mcd, 1200 mcd, 1400 mcd
If - Forward Current: 20 mA
Vf - Forward Voltage: 2 V, 3.1 V, 3.2 V
Wavelength/Color Temperature: 623 nm, 517 nm, 468 nm
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 25 C
