SPECIFICATIONS
Relative Humidity Range: 10 to 95 %RH
Relative Humidity Range: 95 to 98 %RH
Frost Point Temperature Range: –22.0 to 0 °C
Dew Point Temperature Range: –24.5 to 58 °C
Chamber Fluid Temperature Range: 5 to 60 °C
Chamber Fluid Temperature Control Stability: 0.005 °C
Chamber Temperature Uniformity: 0.05 °C
Chamber Fluid Temperature Heating/Cooling Rate: 0.3 °C per Minute (average)
Gas Type: Air or Nitrogen
Gas Pressure Rating: (MAWP) 175 psiG
Gas Flow Rate Range: 1 to 20 L/min
Gas Flow Rate Specification: ±2.5 L/min
Saturation Pressure Range: Ambient to 160 psiA
Test Chamber Pressure Range: Ambient
Supply Pressure Range: Ambient to160 psiG
Supply Pressure Specification: ±1 psiG
Display Resolution: 0.001
Test Chamber Dimensions: 8" x 8" x 8" (203 mm x 203 mm x 203 mm)
Access Port: Ø1.875" (47.6 mm) located on right side
Physical Dimensions: 16.1" H x 27.9" W x 19.2" D (409 mm x 708 mm x 487 mm)
Weight: (Generator Only) 150 lbs (68 kg)
Weight: (Generator, Cart & Air System) 317 lbs (144 kg)
UNCERTAINTY
RH Uncertainty: 10 to 95 %RH, 5 to 60 °C, @ 20 L/min 0.6% of reading
RH Uncertainty: 95 to 98 %RH, 15 to 60 °C, @ 10 L/min 0.6% of reading
Dew/Frost Point Uncertainty: < 0.01 °C, @ 20 L/min 0.05 °C
Dew Point Uncertainty: 0.01 to 58 °C, @ 20 L/min 0.08 °C
Temperature Uncertainty: 5 to 60 °C 0.031 °C
Saturation Pressure: Ambient to 160 psiA 0.037 psiA
Test Chamber Pressure Uncertainty: Ambient 0.007 psiA
Saturation Pressure Specification: 0.02% of full scale
UTILITIES
Electrical Power: 100-240 V~, 5 A, 50/60 Hz
Gas Supply (External): 160 psiG @ 20 L/min
ENVIRONMENTAL
Operating Temperature: 15 to 30 ºC
Storage Temperature: 10 to 50 ºC
Humidity: 5 to 95% Non-condensing
