Tonghui TH2840B 超快速LCR测量仪 (20Hz-2MHz)

Display

+ Display: 10.1" Touch Screen

+ Ratio: 16:09

+ Resolution: 1280×RGB×800

Parameter

+ Test Mode: Four Parameter Selectable

+ AC: Cp/Cs, Lp/Ls, Rp/Rs, |Z|, |Y|, R, X, G, B, θ, D, Q, VAC, IAC

+ DC: RDC, VDC, IDC

Frequency

+ Range: 20Hz-2MHz

+ Accuracy: 0.01%

+ Resolution: 0.1mHz (20.0000Hz-99.9999Hz) - 10Hz (1.00000MHz-2.00000MHz)

Test Level

+ AC Voltage: 5mVrms-20Vrms: F≤1MHz 5mVrms-20Vrms

                                                    F＞1MHz 5mVrms-15Vrms

+ Accuracy: ±（10%×Set Value+2mV) (AC less than 2Vrms);  ±（10%×Set Value+5mV）（AC＞2Vrms）

+ Resolution: 1mVrms（5mVrms-0.2Vrms） - 10mVrms(10Vrms-20Vrms)

+ AC Current: 50μArms-100mArms

+ Resolution (100Ω Internal Resistance): 10μArms (50μArms-2mArms) - 100μArms (50mArms-100mArms)

RDC Test

+ Voltage: 100mV-20V

+ Resolution: 1mV(0V-1V); 10mV(1V-20V)

+ Current: 0mA-100mA

+ Resolution: 10μA(0mA-10mA)

                      100μA(10mA-100mA)

DC Bias

+ Voltage: 0V-±40V

+ Accuracy: AC=<2V 1%× Set Value+5mV

                    AC>2V 2%×Set Value+8mV

+ Resolution: 1mV(0V-1V)

                      10mV(±1V- ±40V)

+ Current: 0 mA-±100 mA

+ Resolution: 10μA(0mA-10mA); 100μA(10mA-100mA)

Cs, Cp: 0.00001pF-9.99999F

Ls, Lp: 0.00001μH-99.9999kH

D: 0.00001-9.99999

Q: 0.00001-99999.9

R, Rs, Rp, X, Z, RDC: 0.001mΩ-99.9999MΩ

G, B, Y: 0.00001μs-99.9999S

VDC: ±0V-±999.999V

IDC: ±0A-±999.999A

θr: -3.14159-3.14159

θd: -179.999°-179.999°

Δ%: ±（0.000%-999.9%）

Input voltage: 100-120VAC/198-242VAC Option, 47-63Hz

Power consumption: More than 130VA

Size (WxHxD): 430x177x265

Weight (kg): 11kg
